To achieve good waterproof effect, color steel plates need to be comprehensively treated from multiple aspects such as material selection, structural design, and construction technology. The following are specific implementation methods:
Material selection is the foundation
Quality control of sheet metal: Select color steel plates with uniform surface coating and appropriate substrate thickness. The coating of high-quality sheet metal (such as galvanized layer) can enhance corrosion resistance and reduce leakage hazards caused by rusting of the sheet metal. For example, color steel plates with a substrate thickness between 0.5-0.8mm and a zinc coating of not less than 180g/m ² have better resistance to deformation and rust.
• Supporting waterproof materials: matched with high-performance waterproof rolls (such as TPO, SBS modified asphalt rolls), waterproof coatings (polyurethane, acrylic), and sealants (silicone sealant, polyurethane sealant), etc. These materials need to have good weather resistance, flexibility, and adhesion, and be able to adapt to the thermal expansion and contraction of color steel plates.
The structural design needs to be reasonable
Slope and drainage design: When installing the roof color steel plate, sufficient slope (generally not less than 5%) should be ensured to allow rainwater to quickly flow into the drainage system. At the same time, the design of gutters and eaves gutters should be spacious and have a reasonable drainage slope to avoid water accumulation. For example, the width of the gutter should not be less than 300mm, and the slope should not be less than 3 ‰ to ensure smooth drainage.
Node construction optimization: Special structural design is carried out at nodes that are prone to water leakage, such as ridges, eaves, internal and external corners, and lighting windows. If a water blocking plate and an additional layer of waterproof membrane are added at the ridge, the color steel plate at the eaves should extend a length of not less than 200mm and be wrapped, and rounded membrane should be used for transition at the internal and external corners to reduce cracking caused by stress concentration.
Construction technology is key
Pre installation base treatment: Before installing the color steel plate, it is necessary to ensure that the base is flat, dry, and clean. If there are unevenness or debris on the base layer, it will affect the adhesion of the color steel plate, form gaps, and cause water leakage. You can first use cement mortar to level it, and then use a broom and hair dryer to clean the surface dust and debris.
Plate installation specifications: When installing color steel plates, the overlap between plates should be accurate and in place. The horizontal overlap should cover a wave peak, with an overlap length of not less than 100mm, and be fixed with self tapping screws. The screw spacing should be controlled at 300-400mm, and waterproof gaskets should be added at the screw positions. When overlapping vertically, the upper and lower plates should be installed with staggered seams to avoid water leakage from straight seams.
Careful sealing treatment: All joints, screw holes, through wall pipes, and other parts must be sealed with sealant. Before applying, it is necessary to clean the surface oil and dust to ensure that the sealant is firmly bonded to the substrate. For example, apply a circle of sealant with a diameter of about 50mm around the screw hole, then tighten the screw, and finally apply another layer of sealant on the screw cap.
Post maintenance is essential
Regular inspection: Every six months to one year, conduct a comprehensive inspection of the color steel plate roof, focusing on checking whether there are sealant cracks, plate deformation, rust, and other conditions at the joints and nodes. Promptly address any issues, such as applying sealant or replacing damaged boards.
• Cleaning and maintenance: Timely clean up fallen leaves, dust, snow and other debris on the roof to avoid the accumulation of debris causing poor drainage. When cleaning, avoid using sharp tools to avoid scratching the surface coating of the color steel plate.
By controlling the entire process from materials, design, construction to maintenance, the waterproof performance of color steel plates can be effectively improved, thereby achieving long-term stable waterproof effect and providing reliable protection for buildings.
