As the core equipment of modern operating rooms, electric operating tables have formed comprehensive advantages far beyond traditional operating tables through technological iteration. Their value is reflected in multiple dimensions such as surgical efficiency, patient safety, and operational convenience, which can be elaborated from the following aspects:
Precise position control improves surgical quality
The electric surgical table achieves multi-dimensional parametric adjustment through servo motors and precision transmission systems. For example, the table lifting accuracy can reach ± 1mm, and the tilt angle control error is ≤ 0.5 °, which can accurately match the position requirements of different surgeries. For example, in neurosurgery, the area of the foramen magnum can be exposed by adjusting the angle of the head plate. During orthopedic joint replacement surgery, the affected limb can be precisely fixed in an anatomical position with a flexion of 30 ° and an external rotation of 15 °, avoiding manual adjustment errors that may result in insufficient exposure of the surgical field of view. At the same time, its stable braking system can ensure that there is no drift in the intraoperative position, especially suitable for long-term microsurgery, reducing operational risks caused by changes in position.
Intelligent operation optimization process efficiency
Compared to manual operating tables that rely on manual adjustment, electric operating tables are equipped with a multimodal control system: foot switches can free doctors’ hands and complete movements such as lifting, tilting, etc. in a sterile state; Infrared remote control allows anesthesiologists to remotely adjust their position next to the monitor; Some high-end models are equipped with touch screen control panels that can store more than 20 sets of surgical position programs, allowing for one click access to commonly used positions such as laparoscopy and open chest surgery, reducing preoperative preparation time by more than 40%. In addition, the dual controller redundancy design ensures that in the event of a single control device failure, the backup system can immediately take over, avoiding surgical interruption.
Multi level security mechanism ensures the safety of doctors and patients
Its safety system covers three levels of protection: mechanical, electronic, and software. At the mechanical level, the lifting column is equipped with a self-locking screw, which automatically locks to prevent the table from falling when power is cut off; On the electronic level, the overcurrent protection device can cut off the power supply when the motor load exceeds the standard, avoiding circuit overload; At the software level, the microprocessor monitors the table load in real-time (usually ranging from 0-200kg), and triggers an emergency stop when the load exceeds the threshold or the adjustment speed is abnormal to prevent the patient from slipping. For special populations, such as children’s operating tables with rounded corners and adjustable restraint straps, memory foam mattresses used by elderly patients can disperse pressure and reduce the risk of pressure ulcers.
Adaptability expands clinical application scenarios
The modular design makes it compatible with various surgical accessories: during orthopedic surgery, a traction frame is added to achieve lower limb extension and reduction; during gynecological surgery, a lithotomy leg frame is used to meet hysteroscopic operation; in neurosurgery, three-point skull positioning is achieved through a head frame fixation system. …
Post time: Aug-11-2025
